Specification Parameter | Honeywell PD45 | Honeywell PD45S |
| Product Brand | Honeywell |
| Category | Printers |
| Series Name | PD Series |
| Print Technology | Direct Thermal / Thermal Transfer |
| Print Resolution | 203 dpi (8 dots/mm) / 300 dpi (11.8 dots/mm) |
| Max Print Width | 108 mm (203 dpi) / 105.7 mm (300 dpi) |
| Max Print Speed | 203 dpi: 50–200 mm/s (2–8 ips) / 300 dpi: 50–100 mm/s (2–4 ips) | 203 dpi: 50–250 mm/s (2–10 ips) / 300 dpi: 50–200 mm/s (2–8 ips) |
| Processor / Memory | ARM Cortex-A7 800 MHz / 128 MB Flash / 256 MB DDR3 SDRAM | ARM Cortex-A7 800 MHz / 256 MB Flash / 256 MB DDR3 SDRAM |
| Media Types | Non-Continuous, Black Mark, Tag, Notch, Continuous Labels | Non-Continuous, Black Mark, Tag, Guide Hole, Notch, Continuous Labels |
| Media Width | 20 mm to 114 mm (0.79 in to 4.5 in) |
| Media Thickness | 3–8.82 mil (0.076–0.224 mm) | 3–10 mil (0.076–0.255 mm) |
| Max Label Roll Diameter | Maximum 203.2 mm (8.0 in) |
| Max Ribbon Length | 450 m; Wax, Mixed Base & Resin Ribbon Support |
| User Interface | 2.36″ Keyed LCD (PD4500C) or LED with Feed Button (PD4500B) | 3.5″ Color Touch LCD (PD45S0F) or 2.36″ Keyed LCD (PD45S0C) |
| Dimensions | 438 × 270 × 249 mm |
| Weight | 9.25 kg | 9.34 kg (PD45S0F) / 9.25 kg (PD45S0C) |
| Power Supply | AC 100–240 V, 50–60 Hz, 100 W PFC Power Supply |
| Operating Temperature | 5°C to 40°C (41°F to 104°F) |
| Standard Interface | USB 2.0 Host, USB 2.0 Device, Ethernet 10/100 Mbps (PD4500C), RS-232 (PD4500C) | USB 2.0 Host, USB 2.0 Device, Ethernet 10/100 Mbps, RS-232 |
| Optional Connectivity | Optional WLAN 802.11 a/b/g/n/ac (PD4500C Only) | Optional WLAN 802.11 a/b/g/n/ac |
| Printer Languages | FP, DP, IPL, ZSim2 (ZPL II), DPL |
| Driver | InterDriver Windows Printer Driver, CUPS Driver for Linux |
| Label Software | Honeywell Label Design and Printing Package |
