Specification Parameter | Newland Soldier 180 | Newland Soldier 300 |
| Product Brand | Newland |
| Category | Scanners |
| Series Name | Soldier Industrial Series |
| Image Sensor | 1280 × 960 / 1600 × 1200 CMOS | 1920 × 1200 CMOS |
| Illumination | 4 High-Intensity Red LEDs | 14 High-Intensity Red LEDs |
| Resolution | 1280 × 960 (W) / 1600 × 1200 | 1D: 0.8–1.67 mil / 2D: 2–3.33 mil |
| Symbologies | 1D, 2D, QR Code, Data Matrix, PDF417, Aztec, Micro QR |
| Motion Tolerance | Standard Industrial | Up to 3.0 m/s |
| Industrial Interfaces | RS-232, TCP/IP, UDP, FTP, Modbus TCP, EtherNet/IP, Profinet, MELSEC | RS-232, RS-485 (Opt), USB, TCP/IP, UDP, FTP, Modbus, EtherNet/IP, Profinet |
| Operating Voltage | 24 VDC |
| Dimensions | 45 × 59.2 × 25 mm | 61 × 57.6 × 101.83 mm |
| Operating Temperature | -20°C to 50°C (-4°F to 122°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Sealing Rating | IP65 Industrial Protection | IP67 Industrial Protection |
